Carbon Steel Pipe
We can help supply all of the Carbon Steel Seamless Pipes or linepipe supplies that your company needs for use in the oil or natural gas industries. API 5L Line Pipe Specifications for these pipes regulate usage for standard Grade A and Grade B pipes, with Grade X indicating stronger variants for drilling, production and transport requirements for offshore, arctic, deep well or harsher environments. Longitudinally welded steel pipes / Carbon Steel Seamless Pipes are used in onshore and offshore oil and gas pipelines requiring critical service, high performance and tight tolerances.
All products are industry-standard conforming to or exceeding API, ASTM, ASME, ANSI and other national and international standards.
API X Grades – some of the sturdiest pipes and tubing available designed for extreme environments or exceedingly high pressure environments
Type | Carbon Steel Seamless Pipes |
---|---|
Pipe Size | Sizes (Seamless): 1/2” NB - 60” NB Sizes (ERW): 1/2” NB - 24” NB Sizes (SAW): 16” NB - 100” NB |
Wall Thickness | SCH10,SCH20,SCH30,STD,SCH40,SCH60,XS,SCH80,SCH100,SCH120, SCH140,SCH160,XXS DIN, JIS standard thickness |
Length | Fixed: 5.8, 6.0, 11.8, 12.0m Random length: 5-12m |
Standard | ASTM A53, A106, API 5L, ASME B36.10M-1996 DIN1626, DIN1629, DIN17175, DIN 2448 JIS G3452, JIS G3454, JIS G3455, JIS G3456, JIS G3457, JIS G3461 |
Material | Q235, Q345, A53B, A106B, API 5L B, X42, X46, X52, X60, X65 ST37.0, ST35.8, St37.2, St35.4/8, St42, St45, St52, St52.4 STP G38, STP G42, STPT42, STB42, STS42, STPT49, STS49 |
Application | Low and middle pressure fluid pipeline, boiler, petroleum and natural gas industry, drilling, chemical industry, electric industry, shipbuilding, fertilizer equipment and pipeline, structure, petrochemical, pharmaceutical industry |
Surface | Black painting, varnish paint, anti rust oil, hot galvanized, cold galvanized, 3PE |
Package | Plastic caps on both ends, Steel bundle, Woven bag or acc. to customers' request |
MOQ | 1 ton |
Production Capacity | 5000 T/M |
Delivery Time | Within 2 Weeks |
Best Rate Guarantee |
High Temperature Seamless Pipe | ASTM A106 Gr. B/C, API 5L Gr. B, ASTM A53 Gr. B |
Heat Exchanger Seamless Tube | ASTM A179 |
Low Temperature Seamless Pipe | ASTM A333 Gr. 3/6 |
Low Temperature Seamless Tube | ASTM A334 Gr. 6 |
High Yield Seamless Pipe | API 5L Gr. X42/X46/X52/X56/X60/X65/X70/X80 PSL-1/PSL-2 |
High Yield Seamless Pipe | ISO 3183 Gr.L245, L290, L320, L360, L390, L415, L450, L485 |
Atmospheric & Low Temp EFW Pipes | ASTM A671 Gr. CC60/CC65/CC70 |
High Pressure & Moderate Temp EFW Pipes | ASTM A672 Gr. B60/B65/B70/C55/C60/C65/C70 |
High Yield ERW/SAW Pipe | API 5L Gr. X42/X46/X52/X56/X60/X65/X70/X80 PSL-1/PSL-2 |
High Yield ERW/SAW Pipe | ISO 3183 Gr.L245, L290, L320, L360, L390, L415, L450, L485 |
Additional Testing :
NACE MR0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc.
Dimensions:
All Pipe is manufactured and inspected/tested to the relevant standards including ASTM, ASME, API.
PSL 1 |
|||||||||
GRADE | Chemical Composition | Mechanical Property | |||||||
C (Max) | Mn (Max) | P (Max) | S (Max) | TENSILE ( Min ) | YIELD ( Min ) | ||||
Psi X 1000 | Mpa | Psi X 1000 | Mpa | ||||||
A25 | CL I | 0.21 | 0.60 | 0.030 | 0.030 | 45 | 310 | 25 | 172 |
CL II | 0.21 | 0.60 | 0.030 | 0.030 | |||||
A | 0.22 | 0.90 | 0.030 | 0.030 | 48 | 331 | 30 | 207 | |
B | 0.26 | 1.20 | 0.030 | 0.030 | 60 | 414 | 35 | 241 | |
X42 | 0.26 | 1.30 | 0.030 | 0.030 | 60 | 414 | 42 | 290 | |
X46 | 0.26 | 1.40 | 0.030 | 0.030 | 63 | 434 | 46 | 317 | |
X52 | 0.26 | 1.40 | 0.030 | 0.030 | 66 | 455 | 52 | 359 | |
X56 | 0.26 | 1.40 | 0.030 | 0.030 | 71 | 490 | 56 | 386 | |
X60 | 0.26 | 1.40 | 0.030 | 0.030 | 75 | 517 | 60 | 414 | |
X65 | 0.26 | 1.45 | 0.030 | 0.030 | 77 | 531 | 65 | 448 | |
X70 | 0.26 | 1.65 | 0.030 | 0.030 | 82 | 565 | 70 | 483 |
PSL 2 | ||||||||||||
GRADE | Chemical Composition | Mechanical Property | ||||||||||
C (Max) | Mn (Max) | P (Max) | S (Max) | Tensile | Yield | C. E. IMPACT ENERGY | ||||||
Psi x 1000 | Mpa | Psi x 1000 | Mpa | PCM | IIW | J | FT/LB | |||||
B | 0.22 | 1.20 | 0.025 | 0.015 | 60 - 110 | 414 - 758 | 35 - 65 | 241 - 448 | 0.25 | 0.43 | T/L 27/41 | T/L 20/30 |
X42 | 0.22 | 1.30 | 0.025 | 0.015 | 60 - 110 | 414 - 758 | 42 - 72 | 290 - 496 | 0.25 | 0.43 | T/L 27/41 | T/L 20/30 |
X46 | 0.22 | 1.40 | 0.025 | 0.015 | 63 - 110 | 434 - 758 | 46 - 76 | 317 - 524 | 0.25 | 0.43 | T/L 27/41 | T/L 20/30 |
X52 | 0.22 | 1.40 | 0.025 | 0.015 | 66 - 110 | 455 - 758 | 52 - 77 | 359 - 531 | 0.25 | 0.43 | T/L 27/41 | T/L 20/30 |
X56 | 0.22 | 1.40 | 0.025 | 0.015 | 71 - 110 | 490 - 758 | 56 - 79 | 386 - 544 | 0.25 | 0.43 | T/L 27/41 | T/L 20/30 |
X60 | 0.22 | 1.40 | 0.025 | 0.015 | 75 - 110 | 517 - 758 | 60 - 82 | 414 - 565 | 0.25 | 0.43 | T/L 27/41 | T/L 20/30 |
X65 | 0.22 | 1.45 | 0.025 | 0.015 | 77 - 110 | 531 - 758 | 65 - 82 | 448 - 565 | 0.25 | 0.43 | T/L 27/41 | T/L 20/30 |
X70 | 0.22 | 1.65 | 0.025 | 0.015 | 82 - 110 | 565 - 758 | 70 - 82 | 483 - 565 | 0.25 | 0.43 | T/L 27/41 | T/L 20/30 |
X80 | 0.22 | 1.90 | 0.025 | 0.015 | 90 - 120 | 621 - 827 | 80 - 102 | 552 - 705 | 0.25 | 0.43 | T/L 27/41 | T/L 20/30 |
