API 5L X 80 PSL 1
We can help supply all of the API 5L X 80 Pipe or linepipe supplies that your company needs for use in the oil or natural gas industries. API 5L Line Pipe Specifications for these pipes regulate usage for standard Grade A and Grade B pipes, with Grade X indicating stronger variants for drilling, production and transport requirements for offshore, arctic, deep well or harsher environments.
API 5L Grade B, x42,x46,x52,X56,x56,x60,x70 Carbon Steel Seamless Pipe Sizes: Schedule 20, Schedule 30, Schedule STD, Schedule 40, Schedule 60, Schedule 80, Schedule 100, Schedule 120, Schedule 160, Schedule XXS in A106 Grade B / A53 Grade B / API 5L Grade B
All products are industry-standard conforming to or exceeding API, ASTM, ASME, ANSI and other national and international standards.
Tubes are visually straight.
API X Grades – some of the sturdiest pipes and tubing available designed for extreme environments or exceedingly high pressure environments
CHEMICAL COMPOSITION | |||||||||||
Mass fraction, based upon heat and product analysis % maximum | CARBON EQUIVALENT a | ||||||||||
% MAXIMUM | |||||||||||
Cb | Si | Mnb | P | S | V | Nb | Ti | Other | CEIIW | CEPcm | |
SEAMLESS & WELDED PIPES | |||||||||||
L485Q or X70Q | 0.18f | 0.45f | 1.8f | 0.025 | 0.015 | g | g | g | h | 0.43 | 0.25 |
WELDED PIPE | |||||||||||
L485M OR X70M | 0.12f | 0.45f | 1.7f | 0.025 | 0.015 | g | g | g | h | 0.43f | 0.25 |
MECHANICAL REQUIREMENTS | |||
Y.S | T.S | ELONGATION | |
Mpa(psi) | Mpa(psi) | ||
min | min | min | |
485(70 300) | 635(92 100) | f |
IMPACT TEST | |||
AVG. ABSORBED ENERGY | IND. ABSORBED ENERGY | ||
Min.(joules) | Min.(joules) | ||
27 | 20 |
Unless otherwise agreed, the sum of the niobium & vanadium concentrations shall be = 0.06%
Unless otherwise agreed, 0.50% maximum for copper, 0.30% maximum for nickel, 0.30% maximum for chromium, & 0.15% maximum for molybdenum.
The sum of the niobium & vanadium & titanium concentrations shall be =0.15%
Unless otherwise agreed, 0.50% maximum for copper, 0.30% maximum for nickel, 0.30% maximum for chromium, & 0.15% maximum for molybdenum.
Unless otherwise agreed g unless otherwise agreed the sum of the niobium & vanadium & titanium concentrations shall be =0.15%
Whether you need API 5L X80 Pipe, standard length and diameter pipes and tubing or you need high strength, high tensile, heavy wall linepipe requirements for deep sour wells, drilling, offshore drilling and production, arctic exploration and production, or you need API 5L X80 Pipe for natural gas, oil or water transport, then Canada Steel and Casing Imports can meet the demands of your company.
