API 5L GR.B PSL 1


We can help supply all of the API 5L GR.B Pipe or linepipe supplies that your company needs for use in the oil or natural gas industries. API 5L Line Pipe Specifications for these pipes regulate usage for standard Grade A and Grade B pipes, with Grade X indicating stronger variants for drilling, production and transport requirements for offshore, arctic, deep well or harsher environments.

All products are industry-standard conforming to or exceeding API, ASTM, ASME, ANSI and other national and international standards.

API X Grades – some of the sturdiest pipes and tubing available designed for extreme environments or exceedingly high pressure environments

CHEMICAL COMPOSITION
Mass fraction, based upon heat and product analysis % maximum CARBON EQUIVALENT a
% MAXIMUM
Cb Si Mnb P S V Nb Ti Other CEIIW CEPcm
SEAMLESS & WELDED PIPES
L485Q or X70Q 0.18f 0.45f 1.8f 0.025 0.015 g g g h 0.43 0.25
WELDED PIPE
L485M OR X70M 0.12f 0.45f 1.7f 0.025 0.015 g g g h 0.43f 0.25
MECHANICAL REQUIREMENTS
Y.S T.S ELONGATION
Mpa(psi) Mpa(psi)
min min min
485(70 300) 635(92 100) f
IMPACT TEST
AVG. ABSORBED ENERGY IND. ABSORBED ENERGY
Min.(joules) Min.(joules)
27 20
Unless otherwise agreed, the sum of Th niobium & vanadium concentrations shall be = 0.06% The sum of Th niobium & vanadium & titanium concentrations shall be = 0.15% Unless otherwise agreed, 0.50% maximum for copper, 0.30% maximum for nickel, 0.30% maximum for chromium, & 0.15% maximum for molybdenum. Whether you need API 5L GR.B Pipe, standard length and diameter pipes and tubing or you need high strength, high tensile, heavy wall line pipe requirements for deep sour wells, drilling, offshore drilling and production, arctic exploration and production, or you need API 5L GR.B Pipe for natural gas, oil or water transport, then Canada Steel And Casing Imports can meet the demands of your company.
