API 5L X 80 PSL 2
We can help supply all of the API 5L X 80 PSL 2 Pipe or linepipe supplies that your company needs for use in the oil or natural gas industries. API 5L Line Pipe Specifications for these pipes regulate usage for standard Grade A and Grade B pipes, with Grade X indicating stronger variants for drilling, production and transport requirements for offshore, arctic, deep well or harsher environments.
API 5L Grade B, x42,x46,x52,X56,x56,x60,X80 Carbon Steel Seamless Pipe Sizes: Schedule 20, Schedule 30, Schedule STD, Schedule 40, Schedule 60, Schedule 80, Schedule 100, Schedule 120, Schedule 160, Schedule XXS in A106 Grade B / A53 Grade B / API 5L Grade B
API 5L X80 PSL2 Pipe Dimensional Range:
API Steel Pipe/API Line Pipe/API Welded Tube R1, R2, R3 J55 K55 N80 L80 X42 X46 X52 X56 X60 X65 X70 X80
| Product Name | API 5L Grade X80 PSL2,API 5L X80 PSL2 | ||
|---|---|---|---|
| Size | OD | 4-1/2″ – 13-3/8″ | |
| Thickness | 0.205 – 0.512 inch | ||
| Length | R1, R2, R3 And Other Length Can Be Provided | ||
| Steel Material | API SPEC 5CT | J55\K55\N80\L80\ | |
| API SPEC 5L | PSL 1 | X42\X46\X52\X56\X60\X65\X70\ X80 | |
| PSL 2 | A25\A\B\X42\X46\X52\X56\X60\ X65 \X70 | ||
| Standard | ASTM, API | ||
| Usage | Oil Pipe, Casing Tube, Line Pipe | ||
| Thread | PTC, STC, LTC, BTC | ||
| Surface | Bared Black Painting, Anti-Corrosion Coating | ||
| Proctor | Plastic Inside And Steel Outside With The Right Threads | ||
| Package | Bags, Bundles, Losses Containers Or Client Option | ||
| Inspection | With Hydraulic Testing, Eddy Current, Infrared and X-ray Test | ||
| Technique | ERW and Hot Rolled/Cold Rolled/ Cold Drawn/SAW | ||
| Type | Spiral or Longitudinal Welded/Seamless | ||
| Certificate | API and ISO 9001:2008 | ||
| Grade B | (ASTM A53, A106, A523) | (API 5LR) | (API 5L PSL2) |
|---|---|---|---|
| Minimum Yield Strength: | 35,000 psi | 35,500 | 35,000 psi |
| Maximum Yield Strength: | None | 65,000 psi | |
| Minimum Tensile Strength: | 60,000 psi | 60,200 | 60,000 psi |
| Maximum Tensile Strength: | None | 110,000 psi | |
| Notes: This grade may be used for standard pipe, line pipe or conduit pipe as specified in the various ASTM and API specifications | |||
Related Standard & Specification: API, DNV, ISO, DEP, EN, ASTM, DIN, BS, JIS, GB
Related Grade: API 5L A-X80, GB/T9711 L190-L555, ASTM A106/A53/A179/A192/A335/A333, DIN1629/17175, JIS G3454/ 3455/3456
Available Approved Marine: ABS/BV/LR/DNV/GL/KR, EN10204 3.2 MTC
Special Service: Sweet Service, Sour Service, Anti-H2S, NACE MR0175/ISO15156
Produce Process: Cold Drawn, Hot Rolled, Hot Expanded
Available Dimension Range: Available Length: 3-36Meters
API 5L X80 PSL2 Pipe – delivery condition and surface
Usually API 5L X80 PSL2 Pipe are supplied as hot rolled. Only tubes with DN 6 -10, perhaps tubes of other dimensions are supplied as cold drawn and after forming they are heat treated. This is done as per precious agreement. The tube surface meets corresponds to the means of manufacturing.
API 5L X80 PSL2 Pipe – straightness
Tubes are visually straight.
Ends of the API 5L X80 PSL2 Pipe
Ends of tubes are smooth, without threads.
From 60.3 diameter beveled according to standards:
DIN, EN – a = 40° – 60°, c = to 2 mm
ASME – a = 75° ± 5°, c = 1,6 ± 0,8 mm
Marking of API 5L X80 PSL2 Pipe and tube bundles
Tubes with diameter up to 1 ½” are marked with label on the bundle. Tubes with larger diameter than 1 ½” are implemented according to directives or upon request.
API 5L X80 PSL2 Pipe – surface protection
Line pipes are supplied without temporary protection against corrosion. Upon request it is possible to deliver tubes with agreed upon anticorrosion protection. The tube ends may be enclosed by a plastic plug.
Certified test reports for line pipe
API 5L
EN 10204 – 2.2, 3.1, 3.2
API X Grades – some of the sturdiest pipes and tubing available designed for extreme environments or exceedingly high pressure environments
| CHEMICAL COMPOSITION | |||||||||||
| Mass fraction, based upon heat and product analysis % maximum | CARBON EQUIVALENT a | ||||||||||
| % MAXIMUM | |||||||||||
| Cb | Si | Mnb | P | S | V | Nb | Ti | Other | CEIIW | CEPcm | |
| SEAMLESS & WELDED PIPES | |||||||||||
| L485Q or X70Q | 0.18f | 0.45f | 1.8f | 0.025 | 0.015 | g | g | g | h | 0.43 | 0.25 |
| WELDED PIPE | |||||||||||
| L485M OR X70M | 0.12f | 0.45f | 1.7f | 0.025 | 0.015 | g | g | g | h | 0.43f | 0.25 |
| MECHANICAL REQUIREMENTS | |||
| Y.S | T.S | ELONGATION | |
| Mpa(psi) | Mpa(psi) | ||
| min | min | min | |
| 485(70 300) | 635(92 100) | f | |
| IMPACT TEST | |||
| AVG. ABSORBED ENERGY | IND. ABSORBED ENERGY | ||
| Min.(joules) | Min.(joules) | ||
| 27 | 20 | ||
Unless otherwise agreed, the sum of the niobium & vanadium concentrations shall be = 0.06%
Unless otherwise agreed, 0.50% maximum for copper, 0.30% maximum for nickel, 0.30% maximum for chromium, & 0.15% maximum for molybdenum.
The sum of the niobium & vanadium & titanium concentrations shall be =0.15%
Unless otherwise agreed, 0.50% maximum for copper, 0.30% maximum for nickel, 0.30% maximum for chromium, & 0.15% maximum for molybdenum.
Unless otherwise agreed g unless otherwise agreed the sum of the niobium & vanadium & titanium concentrations shall be =0.15%
Whether you need API 5L X 80 PSL 2 Pipe, standard length and diameter pipes and tubing or you need high strength, high tensile, heavy wall line pipe requirements for deep sour wells, drilling, offshore drilling and production, arctic exploration and production, or you need API 5L X 80 PSL 2 Pipe for natural gas, oil or water transport, then Canada Steel and Casing Imports can meet the demands of your company.
