API 5L X70 PSL 2

We can help supply all of the API 5L X70 PSL 2 Pipe or linepipe supplies that your company needs for use in the oil or natural gas industries. API 5L Line Pipe Specifications for these pipes regulate usage for standard Grade A and Grade B pipes, with Grade X indicating stronger variants for drilling, production and transport requirements for offshore, arctic, deep well or harsher environments.

API 5L Grade B, x42,x46,x52,X56,x56,x60,x70 Carbon Steel Seamless Pipe Sizes: Schedule 20, Schedule 30, Schedule STD, Schedule 40, Schedule 60, Schedule 80, Schedule 100, Schedule 120, Schedule 160, Schedule XXS in A106 Grade B / A53 Grade B / API 5L Grade B

API 5L X70 PSL2 Pipe Dimensional Range:

Trade Name	API 5L X70 PSL2 Pipe
Weld Alternatives:	ERW, HF, DSAW/SAWL, SMLS, HSAW
OD Size Range:	ERW: 0.375″ through 30″ HF: 0.840″ through 24″ DSAW/SAWL: 12.75″ through 144″ SMLS: 0.840″ through 26″ HSAW: 8.625″ through 144″
Wall Ranges:	ERW: 0.120″ through 1.000″ HF: 0.120″ through 1.000″ DSAW/SAWL: 0.250″ through 6.000″ SMLS: 0.250″ through 2.500″ HSAW: 0.250″ through 1.000″
Lengths:	Single Random Double Random Custom (up to 300′)
Grade:	ASTM A53, ASTM A106, ASTM A179, ASTM A192, ST35.8, ST37, ST42, ST52, E235, E355, S235JRH, S275JR, S355JOH, P235TR1, 10#, 20#, 45#, Q235, Q345
Schedule:	SCH5 SCH10 SCH20 SCH30 SCH40 SCH80 SCH120 SCH140 SCH160 SCHXS SCHXXS
Surface Finishes:	Bare, Oiled, Mill Varnish, Galv, FBE, FBE Dual, 3LPE, 3LPP, Coal Tar, Concrete Coating and Tape Wrap.
End Finishes:	Beveled, Square Cut, Threaded & Coupled.
Additional Services:	Internal Coating

API 5L X70 PSL2 Pipe features:

The American Petroleum Institute specification API 5L covers seamless and welded steel line pipe. API 5L, 45th Edition / ISO 3183 This is steel pipe for pipeline transportation systems in the petroleum and natural gas industries API 5L X70 PSL2 Pipe is suitable for conveying gas, water, and oil. API 5L X70 PSL2 Pipe, high yield seamless pipes, modified to suit offshore structural purposes. Suitable for weldable structural steels for fixed offshore structures Ashtapad’s seamless and extra long ERW API 5L Line Pipe for dependable transmission of oil and gas to any type of collection and distribution point. As only the edges are heated, the tube possesses dean accurate surface. Safety is better than smls pipe. The cost is cheaper than smls pipe and LSAW pipe. Manufacturing speed is quicker than seamless pipe or sub merged welded pipes.

API 5L X70 PSL2 Pipe – delivery condition and surface

Usually API 5L X70 PSL2 Pipe are supplied as hot rolled. Only tubes with DN 6 -10, perhaps tubes of other dimensions are supplied as cold drawn and after forming they are heat treated. This is done as per precious agreement. The tube surface meets corresponds to the means of manufacturing.

API 5L X70 PSL2 Pipe – straightness

Tubes are visually straight.

Ends of the API 5L X70 PSL2 Pipe

Ends of tubes are smooth, without threads. From 60.3 diameter beveled according to standards: DIN, EN – a = 40° – 60°, c = to 2 mm ASME – a = 75° ± 5°, c = 1,6 ± 0,8 mm

Marking of API 5L X70 PSL2 Pipe and tube bundles

Tubes with diameter up to 1 ½” are marked with label on the bundle. Tubes with larger diameter than 1 ½” are implemented according to directives or upon request.

API 5L X70 PSL2 Pipe – surface protection

Line pipes are supplied without temporary protection against corrosion. Upon request it is possible to deliver tubes with agreed upon anticorrosion protection. The tube ends may be enclosed by a plastic plug. API X Grades – some of the sturdiest pipes and tubing available designed for extreme environments or exceedingly high pressure environments

CHEMICAL COMPOSITION
Mass fraction, based upon heat and product analysis % maximum										CARBON EQUIVALENT a
										% MAXIMUM
Cb		Si	Mnb	P	S	V	Nb	Ti	Other	CEIIW	CEPcm
SEAMLESS & WELDED PIPES
L485Q or X70Q	0.18f	0.45f	1.8f	0.025	0.015	g	g	g	h	0.43	0.25
WELDED PIPE
L485M OR X70M	0.12f	0.45f	1.7f	0.025	0.015	g	g	g	h	0.43f	0.25

MECHANICAL REQUIREMENTS
Y.S	T.S	ELONGATION
Mpa(psi)	Mpa(psi)
min	min	min
485(70 300)	635(92 100)	f

IMPACT TEST
AVG. ABSORBED ENERGY	IND. ABSORBED ENERGY
Min.(joules)	Min.(joules)
27	20

Unless otherwise agreed, the sum of th niobium & vanadum concentrations shall be = 0.06% Unless otherwise agreed, 0.50% maximum for copper, 0.30% maximum for nickel, 0.30% maximum for chromium, & 0.15% maximum for molybdenum. The sum of th niobium & vanadum & titanium concentrations shall be =0.15% Unless otherwise agreed, 0.50% maximum for copper, 0.30% maximum for nickel, 0.30% maximum for chromium, & 0.15% maximum for molybdenum. Unless otherwise agreed g unless otheriwse agreed the sum of th niobium & vanadum & titanium concentrations shall be =0.15%

Whether you need API 5L X70 PSL 2 Pipe, standard length and diameter pipes and tubing or you need high strength, high tensile, heavy wall linepipe requirements for deep sour wells, drilling, offshore drilling and production, arctic exploration and production, or you need API 5L X70 PSL 2 Pipe for natural gas, oil or water transport, then Canada Steel and Casing Imports can meet the demands of your company.
