API 5L X52 PSL 2
We can help supply all of the API 5L X52 PSL 2 Pipe or linepipe supplies that your company needs for use in the oil or natural gas industries. API 5L Line Pipe Specifications for these pipes regulate usage for standard Grade A and Grade B pipes, with Grade X indicating stronger variants for drilling, production and transport requirements for offshore, arctic, deep well or harsher environments.
API 5L Grade B, x42,x46,x52,X56,x56,x60,x70 Carbon Steel Seamless Pipe Sizes: Schedule 20, Schedule 30, Schedule STD, Schedule 40, Schedule 60, Schedule 80, Schedule 100, Schedule 120, Schedule 160, Schedule XXS in A106 Grade B / A53 Grade B / API 5L Grade B
API 5L X52 PSL2 Pipe Dimensional Range & Standard Specification
API 5L X52 PSL2 Pipe Dimensional Range:
Trade Name | API 5L X52 PSL2 Pipe |
---|---|
Weld Alternatives: | ERW, HF, DSAW/SAWL, SMLS, HSAW |
OD Size Range: | ERW: 0.375″ through 30″ HF: 0.840″ through 24″ DSAW/SAWL: 12.75″ through 144″ SMLS: 0.840″ through 26″ HSAW: 8.625″ through 144″ |
Wall Ranges: | ERW: 0.120″ through 1.000″ HF: 0.120″ through 1.000″ DSAW/SAWL: 0.250″ through 6.000″ SMLS: 0.250″ through 2.500″ HSAW: 0.250″ through 1.000″ |
Lengths: | Single Random Double Random Custom (up to 300′) |
Grade: | ASTM A53, ASTM A106, ASTM A179, ASTM A192, ST35.8, ST37, ST42, ST52, E235, E355, S235JRH, S275JR, S355JOH, P235TR1, 10#, 20#, 45#, Q235, Q345 |
Schedule: | SCH5 SCH10 SCH20 SCH30 SCH40 SCH80 SCH120 SCH140 SCH160 SCHXS SCHXXS |
Surface Finishes: | Bare, Oiled, Mill Varnish, Galv, FBE, FBE Dual, 3LPE, 3LPP, Coal Tar, Concrete Coating and Tape Wrap. |
End Finishes: | Beveled, Square Cut, Threaded & Coupled. |
Additional Services: | Internal Coating |
API 5L X52 | (PSL2) |
---|---|
Minimum Yield Strength: | 52,200 psi |
Maximum Yield Strength: | 76,900 psi |
Minimum Tensile Strength: | 66,700 psi |
Maximum Tensile Strength: | 110,200 psi |
Notes: This is a standard line pipe grade specified in API (American Petroleum Institute) specification 5L. |
API 5L X52 Industry Specifications | Chemical Composition | Yield Strength min. (KSI) | Tensile Strength min. (KSI) | Yield to Tensile Ratio (max) | Elongation % |
ASTM A105, A106, A234, A333, A350, A420, A694,A860 | C 0.16 Mn 1.60 Si 0.15-0.50 S 0.007 P 0.025 Cu 0.30 Ni 0.30 Cr 0.25 Mo 0.08 V 0.06 Nb 0.04 Ti 0.02 Sn 0.02 B 0.0005 N 0.014 Al 0.06 max | 52 | 66 | 0.93 | 21 |
API 5L X52
Grade X52 indicates 52000 PSI minimum yield strength and 66000 PSI minimum ultimate tensile strength.
API Standard Specification for Line Pipe
Related Standard & Specification: API, DNV, ISO, DEP, EN, ASTM, DIN, BS, JIS, GB
Related Grade: API 5L A-X80, GB/T9711 L190-L555, ASTM A106/A53/A179/A192/A335/A333, DIN1629/17175, JIS G3454/ 3455/3456
Available Approved Marine: ABS/BV/LR/DNV/GL/KR, EN10204 3.2 MTC
Special Service: Sweet Service, Sour Service, Anti-H2S, NACE MR0175/ISO15156
Produce Process: Cold Drawn, Hot Rolled, Hot Expanded
Available Dimension Range: Available Length: 3-36 Meters
Grade B | (ASTM A53, A106, A523) | (API 5LR) | (API 5L PSL2) |
---|---|---|---|
Minimum Yield Strength: | 35,000 psi | 35,500 | 35,000 psi |
Maximum Yield Strength: | None | 65,000 psi | |
Minimum Tensile Strength: | 60,000 psi | 60,200 | 60,000 psi |
Maximum Tensile Strength: | None | 110,000 psi | |
Notes: This grade may be used for standard pipe, line pipe or conduit pipe as specified in the various ASTM and API specifications |
The American Petroleum Institute specification API 5L addresses seamless and welded steel line pipe for pipeline transportation systems in the petroleum and natural gas industries. API 5L is suitable for conveying gas, water, and oil.
Grades covered by this specification are A25, A, B and “X” Grades X42, X46, X52, X56, X60, X65, X70, and X80. The two digit number following the “X” indicates the Minimum Yield Strength (in 000’s psi) of pipe produced to this grade.
Production Standards & Material Qualities
API 5L L245 / Gr. B (PSL 1) API 5L L290 / X42 (PSL 1) API 5L L245 / Gr. B (PSL 2) API 5L L290 / Gr. B (PSL 2) API 5L L320 / X46 (PSL 1) API 5L L320 / X46 (PSL 2) | API 5L L360 / X52 (PSL 1) API 5L L360 / X52 (PSL 2) API 5L L415 / X60 (PSL 1) API 5L L415 / X60 (PSL 2) API 5L L450 / X65 (PSL 1) API 5L L450 / X65 (PSL 2) |
Line Pipe API 5L, PSL 1, PSL 2 CSA Z 245.1 EN ISO 3183 GOST 20295 | Gr A, X70-(N, M) Gr 241-Gr 359 L 245-L485 (N, M, NE, ME) K34-K60 |
Line pipe – types of steel
Tubes for transportation of flammable fluids are made of the following steels, according to EN 10208-1: L210GA, L235GA, L245GA, L290GA, L360GA, according to EN 10208-2: L245NB, L290NB, L360NB, L415NB and according to API 5L: Grade A, Grade B, Grade X42, Grade X46, Grade X52, Grade X60. Additional types of steel (according to DIN 2470-1/1629 and 2470-2/17172 and UNI 7088) together with its chemicals composition and mechanical properties are shown in a separate overview.. Steel is made in the electric arc furnace and it is fully killed.
CHEMICAL COMPOSITION | |||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|
Mass fraction, based upon heat and product analysis % maximum | CARBON EQUIVALENT a | ||||||||||
% MAXIMUM | |||||||||||
Cb | Si | Mnb | P | S | V | Nb | Ti | Other | CEIIW | CEPcm | |
SEAMLESS & WELDED PIPES | |||||||||||
L290R OR X42R | 0.24 | 0.4 | 1.2 | 0.025 | 0.015 | 0.06 | 0.05 | 0.04 | e | 0.43 | 0.25 |
L290Q OR X42Q | 0.18 | 0.45 | 1.4 | 0.025 | 0.015 | 0.05 | 0.05 | 0.04 | e | 0.43 | 0.25 |
WELDED PIPE | |||||||||||
L290M OR X42M | 0.22 | 0.45 | 1.3 | 0.025 | 0.015 | 0.05 | 0.05 | 0.04 | e | 0.43 | 0.25 |
Chemical Analysis(%) For Part Standard -PSL2
Standard | Class | Grade | C | Si | Mn | P | S | V | Nb | Ti |
---|---|---|---|---|---|---|---|---|---|---|
max | max | max | max | max | max | max | max | |||
APL 5L ISO 3181 | PSL2 | L245R or BR | 0.24 | 0.40 | 1.20 | 0.025 | 0.015 | d | d | 0.04 |
L290R or X42R | 0.24 | 0.40 | 1.20 | 0.025 | 0.015 | 0.06 | 0.05 | 0.04 | ||
L245N or BN | 0.24 | 0.40 | 1.20 | 0.025 | 0.015 | d | d | 0.04 | ||
L290N or X42N | 0.24 | 0.40 | 1.20 | 0.025 | 0.015 | 0.06 | 0.05 | 0.04 | ||
L320N or X46N | 0.24 | 0.40 | 1.40 | 0.025 | 0.015 | 0.07 | 0.05 | 0.04 | ||
L360N or X52N | 0.24 | 0.45 | 1.40 | 0.025 | 0.015 | 0.10 | 0.05 | 0.04 | ||
L390N or X56N | 0.24 | 0.45 | 1.40 | 0.025 | 0.015 | 0.10 | 0.05 | 0.04 | ||
L415N or X60N | 0.24 | 0.45 | 1.40 | 0.025 | 0.015 | 0.10 | 0.05 | 0.04 | ||
L245Q or BQ | 0.18 | 0.45 | 1.40 | 0.025 | 0.015 | 0.05 | 0.05 | 0.04 | ||
L290Q or X42Q | 0.18 | 0.45 | 1.40 | 0.025 | 0.015 | 0.05 | 0.05 | 0.04 | ||
L320Q or X46Q | 0.18 | 0.45 | 1.40 | 0.025 | 0.015 | 0.05 | 0.05 | 0.04 | ||
L360Q or X52Q | 0.18 | 0.45 | 1.50 | 0.025 | 0.015 | 0.05 | 0.05 | 0.04 | ||
L390Q or X56Q | 0.18 | 0.45 | 1.50 | 0.025 | 0.015 | 0.07 | 0.05 | 0.04 | ||
L415Q or X60Q | 0.18 | 0.45 | 1.70 | 0.025 | 0.015 | c | c | c | ||
L450Q or X65Q | 0.18 | 0.45 | 1.70 | 0.025 | 0.015 | c | c | c | ||
L485Q or X70Q | 0.18 | 0.45 | 1.80 | 0.025 | 0.015 | c | c | c | ||
L555Q or X80Q | 0.18 | 0.45 | 1.90 | 0.025 | 0.015 | c | c | c | ||
L625Q or X90Q | 0.16 | 0.45 | 1.90 | 0.020 | 0.010 | c | c | c | ||
L690Q or X100Q | 0.16 | 0.45 | 1.90 | 0.020 | 0.010 | c | c | c | ||
L245M or BM | 0.22 | 0.45 | 1.20 | 0.025 | 0.015 | 0.05 | 0.05 | 0.04 | ||
L290M or X42M | 0.22 | 0.45 | 1.30 | 0.025 | 0.015 | 0.05 | 0.05 | 0.04 | ||
L320M or X46M | 0.22 | 0.45 | 1.30 | 0.025 | 0.015 | 0.05 | 0.05 | 0.04 | ||
L360M or X52M | 0.22 | 0.45 | 1.40 | 0.025 | 0.015 | b | b | b | ||
L390M or X56M | 0.22 | 0.45 | 1.40 | 0.025 | 0.015 | b | b | b | ||
L415M or X60M | 0.12 | 0.45 | 1.60 | 0.025 | 0.015 | c | c | c | ||
L450M or X65M | 0.12 | 0.45 | 1.60 | 0.025 | 0.015 | c | c | c | ||
L485M or X70M | 0.12 | 0.45 | 1.70 | 0.025 | 0.015 | c | c | c | ||
L555M or X80M | 0.12 | 0.45 | 1.85 | 0.025 | 0.015 | c | c | c | ||
L625M or X90M | 0.10 | 0.55 | 2.10 | 0.020 | 0.010 | c | c | c | ||
L690M or X100M | 0.10 | 0.55 | 2.10 | 0.020 | 0.010 | c | c | c |
Mechanical Properties
Standard | Class | Grade | Yield Strength MPa | Yield Strength MPa | Y.S/T.S | ||
---|---|---|---|---|---|---|---|
min | max | min | max | max | |||
API 5L ISO3183 | PSL2 | L245R or BR L245N or BN L245Q or BQ L245M or BM | 245 | 450 | 415 | 655 | 0.93 |
L290R or X42R L290N or X42N L290Q or X42Q L290M or X42M | 290 | 495 | 415 | 655 | 0.93 | ||
L320N or X46N L320Q or X46Q L320M or X46M | 320 | 525 | 435 | 655 | 0.93 | ||
L360N or X52N L360Q or X52Q L360M or X52M | 360 | 530 | 460 | 760 | 0.93 | ||
L390N or X56N L390Q or X56Q L390M or X56M | 390 | 545 | 490 | 760 | 0.93 | ||
L415N or X60N L415Q or X60Q L415M or X60M | 415 | 565 | 520 | 760 | 0.93 | ||
L450Q or X65Q L450M or X65M | 450 | 600 | 535 | 760 | 0.93 | ||
L485Q or X70Q L485M or X70M | 485 | 635 | 570 | 760 | 0.93 | ||
L555Q or X80Q L555M or X80M | 555 | 705 | 625 | 825 | 0.93 | ||
L625M or X90M L625Q or X90Q | 625 | 775 | 695 | 915 | 0.95 | ||
L690M or X100M L690Q or X100Q | 690 | 840 | 760 | 990 | 0.97 |
Minimum Impact Energy
Standard
Specified Outside Diameter | Grade | Charp Imapct Test 0℃ | ||
---|---|---|---|---|
Impact of Pipe Body | Impact of Weld | |||
API 5L ISO3183 | D≤762mm | ≤L485 or X70 | 27 | 27 |
L555 or X80 | 40 | 27 | ||
762mm< td="" style="box-sizing: border-box;"><> | ≤L555 or X80 | 40 | 27 | |
1219mm< td="" style="box-sizing: border-box;"><> | ≤L415 or X60 | 40 | 27 | |
>L415 or X60 ≤L555 or X80 | 54 | 27 | ||
>1422mm | ≤L415 or X60 | 40 | 40 | |
>L415 or X60 ≤L555 or X80 | 54 | 40 |
API 5L X52 PSL2 Pipe features:
The American Petroleum Institute specification API 5L covers seamless and welded steel line pipe.
API 5L, 45th Edition / ISO 3183
This is steel pipe for pipeline transportation systems in the petroleum and natural gas industries
API 5L X52 PSL2 Pipe is suitable for conveying gas, water, and oil.
API 5L X52 PSL2 Pipe, high yield seamless pipes, modified to suit offshore structural purposes.
Suitable for weldable structural steels for fixed offshore structures
Ashtapad’s seamless and extra long ERW API 5L Line Pipe for dependable transmission of oil and gas to any type of collection and distribution point.
As only the edges are heated, the tube possesses dean accurate surface.
Safety is better than smls pipe.
The cost is cheaper than smls pipe and LSAW pipe.
Manufacturing speed is quicker than seamless pipe or sub merged welded pipes.
API 5L X52 PSL2 Pipe – delivery condition and surface
Usually API 5L X52 PSL2 Pipe are supplied as hot rolled. Only tubes with DN 6 -10, perhaps tubes of other dimensions are supplied as cold drawn and after forming they are heat treated. This is done as per precious agreement. The tube surface meets corresponds to the means of manufacturing.
API 5L X52 PSL2 Pipe – straightness
Tubes are visually straight.
Ends of the API 5L X52 PSL2 Pipe
Ends of tubes are smooth, without threads.
From 60.3 diameter beveled according to standards:
DIN, EN – a = 40° – 60°, c = to 2 mm
ASME – a = 75° ± 5°, c = 1,6 ± 0,8 mm
Marking of API 5L X52 PSL2 Pipe and tube bundles
Tubes with diameter up to 1 ½” are marked with label on the bundle. Tubes with larger diameter than 1 ½” are implemented according to directives or upon request.
API 5L X52 PSL2 Pipe – surface protection
Line pipes are supplied without temporary protection against corrosion. Upon request it is possible to deliver tubes with agreed upon anticorrosion protection. The tube ends may be enclosed by a plastic plug.
API X Grades – some of the sturdiest pipes and tubing available designed for extreme environments or exceedingly high pressure environments
CHEMICAL COMPOSITION | |||||||||||
Mass fraction, based upon heat and product analysis % maximum | CARBON EQUIVALENT a | ||||||||||
% MAXIMUM | |||||||||||
Cb | Si | Mnb | P | S | V | Nb | Ti | Other | CEIIW | CEPcm | |
SEAMLESS & WELDED PIPES | |||||||||||
L485Q or X70Q | 0.18f | 0.45f | 1.8f | 0.025 | 0.015 | g | g | g | h | 0.43 | 0.25 |
WELDED PIPE | |||||||||||
L485M OR X70M | 0.12f | 0.45f | 1.7f | 0.025 | 0.015 | g | g | g | h | 0.43f | 0.25 |
MECHANICAL REQUIREMENTS | |||
Y.S | T.S | ELONGATION | |
Mpa(psi) | Mpa(psi) | ||
min | min | min | |
485(70 300) | 635(92 100) | f |
IMPACT TEST | |||
AVG. ABSORBED ENERGY | IND. ABSORBED ENERGY | ||
Min.(joules) | Min.(joules) | ||
27 | 20 |
Unless otherwise agreed, the sum of th niobium & vanadum concentrations shall be = 0.06%
Unless otherwise agreed, 0.50% maximum for copper, 0.30% maximum for nickel, 0.30% maximum for chromium, & 0.15% maximum for molybdenum.
The sum of th niobium & vanadum & titanium concentrations shall be =0.15%
Unless otherwise agreed, 0.50% maximum for copper, 0.30% maximum for nickel, 0.30% maximum for chromium, & 0.15% maximum for molybdenum.
Unless otherwise agreed g unless otheriwse agreed the sum of th niobium & vanadum & titanium concentrations shall be =0.15%
Whether you need API 5L X52 PSL 2 Pipe, standard length and diameter pipes and tubing or you need high strength, high tensile, heavy wall linepipe requirements for deep sour wells, drilling, offshore drilling and production, arctic exploration and production, or you need API 5L X52 PSL 2 Pipe for natural gas, oil or water transport, then Canada Steel and Casing Imports can meet the demands of your company.
