API 5L X 56 PSL 1
We can help supply all of the API 5L X 56 Pipe or line pipe supplies that your company needs for use in the oil or natural gas industries. API 5L Line Pipe Specifications for these pipes regulate usage for standard Grade A and Grade B pipes, with Grade X indicating stronger variants for drilling, production, and transport requirements for offshore, arctic, deep well, or harsher environments. Grade X52 is the most popular selling grade in carbon steel seamless pipes.
Descripstion | GRADE | Size | SCH | PRICE PER TON IN USD |
---|---|---|---|---|
Carbon steel SMLS Pipe | api 5l x56 psl1 pipe api 5l x56 psl2 pipe | 1/2" To 24" | 10, 20, 30, STD, 40, 60, XS, 80, 100, 120, 140, 160, XXS | 1200 TO 1400 |
Carbon steel SMLS Pipe | api 5l x56 psl1 pipe api 5l x56 psl2 pipe | 1/2" To 24" | 10, 20, 30, STD, 40, 60, XS, 80, 100, 120, 140, 160, XXS | 1400 TO 2000 |
Carbon steel ERW, LSAW, SAW, EFW Pipe | api 5l x56 psl1 pipe api 5l x56 psl2 pipe | 16" To 84" | 10, 20, 30, STD, 40, 60, XS, 80, 100, 120, 140, 160, XXS | 800 TO 1000 |
Carbon steel ERW, LSAW, SAW, EFW Pipe | api 5l x56 psl1 pipe api 5l x56 psl2 pipe | 16" To 84" | 10, 20, 30, STD, 40, 60, XS, 80, 100, 120, 140, 160, XXS | 1000 TO 1300 |
API 5L X56 PSL1 Pipe Dimensional Range & Standard Specification
API 5L X56 PSL1 Pipe Dimensional Range:
Related Standard & Specification: API, DNV, ISO, DEP, EN, ASTM, DIN, BS, JIS, GB
Related Grade: API 5L A-X80, GB/T9711 L190-L555, ASTM A106/A53/A179/A192/A335/A333, DIN1629/17175, JIS G3454/ 3455/3456
Available Approved Marine: ABS/BV/LR/DNV/GL/KR, EN10204 3.2 MTC
Special Service: Sweet Service, Sour Service, Anti-H2S, NACE MR0175/ISO15156
Produce Process: Cold Drawn, Hot Rolled, Hot Expanded
Available Dimension Range: Available Length: 3-36Meters
Note:- | |
---|---|
Trade name |
API 5L X56 PSL1 Pipe |
Other Specification
Available |
API 5L – A,B, X – 42, 46, 52, 56,
60, 65, 70, 80 |
Special Tube |
Saw Pipes & Steam Pipes
Precision Tubes
Fabricated Pipe (with radiography) |
In Form of |
Round
Hydraulic Tube &
Horn Tube. |
In Length of |
Standard
Double &
In Cut length also. |
Value Added Service |
Draw & Expansion as per required Size & Length Heat Treatment Bending Galvanizing Annealed Sand Blasting Machining Etc. |
Test Certificate |
Manufacturer Test Certificate IBR Test Certificate (Form III-D) Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection with Excise Gate Pass to avail Modvat benefit. |
API 5L X56 | (PSL1) | (PSL2) |
Minimum Yield Strength: | 56,600 psi | 56,600 psi |
Maximum Yield Strength: | None | 79,000 psi |
Minimum Tensile Strength: | 71,100 psi | 71,100 psi |
Maximum Tensile Strength: | None | 110,200 psi |
Notes: This is a standard line pipe grade specified in API (American Petroleum Institute) specification 5L. |
Line pipe – types of steel
Tubes for transportation of flammable fluids are made of the following steels, according to EN 10208-1: L210GA, L235GA, L245GA, L290GA, L360GA, according to EN 10208-2: L245NB, L290NB, L360NB, L415NB and according to API 5L: Grade A, Grade B, Grade X42, Grade X46, Grade X52, Grade X60. Additional types of steel (according to DIN 2470-1/1629 and 2470-2/17172 and UNI 7088) together with its chemicals composition and mechanical properties are shown in a separate overview.. Steel is made in the electric arc furnace and it is fully killed.
Chemical Analysis(%) For Part Standard
Standard | Class | Grade | C | Si | Mn | P | S | V | Nb | Ti |
---|---|---|---|---|---|---|---|---|---|---|
max | max | max | max | max | max | max | max | |||
APL 5L ISO 3181 | PSL1 | L245 or B | 0.26 | - | 1.20 | 0.030 | 0.030 | - | - | - |
L290 or X42 | 0.26 | - | 1.30 | 0.030 | 0.030 | - | - | - | ||
L320 or X46 | 0.26 | - | 1.40 | 0.030 | 0.030 | a,b | a,b | b | ||
L360 or X52 | 0.26 | - | 1.40 | 0.030 | 0.030 | b | b | b | ||
L390 or X56 | 0.26 | - | 1.40 | 0.030 | 0.030 | b | b | b | ||
L415 or X60 | 0.26 | - | 1.40 | 0.030 | 0.030 | c | c | c | ||
L450 or X65 | 0.26 | - | 1.45 | 0.030 | 0.030 | c | c | c | ||
L485 or X70 | 0.26 | - | 1.65 | 0.030 | 0.030 | c | c | c |
Mechanical Properties
Standard | Specified Outside Diameter | Grade | Charp Imapct Test 0℃ | |
---|---|---|---|---|
Impact of Pipe Body | Impact of Weld | |||
API 5L ISO3183 | D≤762mm | ≤L485 or X70 | 27 | 27 |
L555 or X80 | 40 | 27 | ||
762mm< td="" style="box-sizing: border-box;"><> | ≤L555 or X80 | 40 | 27 | |
1219mm< td="" style="box-sizing: border-box;"><> | ≤L415 or X60 | 40 | 27 | |
>L415 or X60 ≤L555 or X80 | 54 | 27 | ||
>1422mm | ≤L415 or X60 | 40 | 40 | |
>L415 or X60 ≤L555 or X80 | 54 | 40 |
Standard | Class | Grade | Yield Strength MPa | Yield Strength MPa | Y.S/T.S | ||
---|---|---|---|---|---|---|---|
min | max | min | max | max | |||
API 5L ISO3183 | PSL2 | L245R or BR L245N or BN L245Q or BQ L245M or BM | 245 | 450 | 415 | 655 | 0.93 |
L290R or X42R L290N or X42N L290Q or X42Q L290M or X42M | 290 | 495 | 415 | 655 | 0.93 | ||
L320N or X46N L320Q or X46Q L320M or X46M | 320 | 525 | 435 | 655 | 0.93 | ||
L360N or X52N L360Q or X52Q L360M or X52M | 360 | 530 | 460 | 760 | 0.93 | ||
L390N or X56N L390Q or X56Q L390M or X56M | 390 | 545 | 490 | 760 | 0.93 | ||
L415N or X60N L415Q or X60Q L415M or X60M | 415 | 565 | 520 | 760 | 0.93 | ||
L450Q or X65Q L450M or X65M | 450 | 600 | 535 | 760 | 0.93 | ||
L485Q or X70Q L485M or X70M | 485 | 635 | 570 | 760 | 0.93 | ||
L555Q or X80Q L555M or X80M | 555 | 705 | 625 | 825 | 0.93 | ||
L625M or X90M L625Q or X90Q | 625 | 775 | 695 | 915 | 0.95 | ||
L690M or X100M L690Q or X100Q | 690 | 840 | 760 | 990 | 0.97 |
Minimum Impact Energy
API 5L X56 PSL1 Pipe – delivery condition and surface
Usually, API 5L X56 PSL1 pipes are supplied as hot rolled. Only tubes with DN 6 -10, perhaps tubes of other dimensions are supplied as cold drawn and after forming they are heat treated. This is done as per precious agreement. The tube surface meets corresponds to the means of manufacturing.
API 5L X56 PSL1 Pipe – straightness
Tubes are visually straight.
Ends of the API 5L X56 PSL1 Pipe
The ends of the tubes are smooth, without threads.
From 60.3 diameter beveled according to standards:
DIN, EN – a = 40° – 60°, c = to 2 mm
ASME – a = 75° ± 5°, c = 1,6 ± 0,8 mm
Marking of API 5L X56 PSL1 Pipe and tube bundles
Tubes with diameters up to 1 ½” are marked with label on the bundle. Tubes with larger diameters than 1 ½” are implemented according to directives or upon request.
API 5L X56 PSL1 Pipe – surface protection
Line pipes are supplied without temporary protection against corrosion. Upon request it is possible to deliver tubes with agreed upon anticorrosion protection. The tube ends may be enclosed by a plastic plug.
All products are industry-standard conforming to or exceeding API, ASTM, ASME, ANSI and other national and international standards.
API X Grades – some of the sturdiest pipes and tubing available designed for extreme environments or exceedingly high-pressure environments
CHEMICAL COMPOSITION | |||||||||||
Mass fraction, based upon heat and product analysis % maximum | CARBON EQUIVALENT a | ||||||||||
% MAXIMUM | |||||||||||
Cb | Si | Mnb | P | S | V | Nb | Ti | Other | CEIIW | CEPcm | |
SEAMLESS & WELDED PIPES | |||||||||||
L485Q or X70Q | 0.18f | 0.45f | 1.8f | 0.025 | 0.015 | g | g | g | h | 0.43 | 0.25 |
WELDED PIPE | |||||||||||
L485M OR X70M | 0.12f | 0.45f | 1.7f | 0.025 | 0.015 | g | g | g | h | 0.43f | 0.25 |
MECHANICAL REQUIREMENTS | |||
Y.S | T.S | ELONGATION | |
Mpa(psi) | Mpa(psi) | ||
min | min | min | |
485(70 300) | 635(92 100) | f |
IMPACT TEST | |||
AVG. ABSORBED ENERGY | IND. ABSORBED ENERGY | ||
Min.(joules) | Min.(joules) | ||
27 | 20 |
Unless otherwise agreed, the sum of the niobium & vanadium concentrations shall be = 0.06%
Unless otherwise agreed, 0.50% maximum for copper, 0.30% maximum for nickel, 0.30% maximum for chromium, & 0.15% maximum for molybdenum.
The sum of the niobium & vanadium & titanium concentrations shall be =0.15%
Unless otherwise agreed, 0.50% maximum for copper, 0.30% maximum for nickel, 0.30% maximum for chromium, & 0.15% maximum for molybdenum.
Unless otherwise agreed g unless otherwise agreed the sum of the niobium & vanadium & titanium concentrations shall be =0.15%
Whether you need API 5L X56 Pipe, standard length and diameter pipes and tubing or you need high strength, high tensile, heavy wall line pipe requirements for deep sour wells, drilling, offshore drilling and production, arctic exploration and production, or you need API 5L X56 Pipe for natural gas, oil or water transport, then Canada Steel and Casing Imports can meet the demands of your company.
