API 5L LSAW Pipe

We can help supply all of the Carbon Steel LSAW Pipes or linepipe supplies that your company needs for use in the oil or natural gas industries. API 5L Line Pipe Specifications for these pipes regulate usage for standard Grade A and Grade B pipes, with Grade X indicating stronger variants for drilling, production and transport requirements for offshore, arctic, deep well or harsher environments. Longitudinally welded steel pipes / Carbon Steel LSAW Pipes are used in onshore and offshore oil and gas pipelines requiring critical service, high performance and tight tolerances.
All products are industry-standard conforming to or exceeding API, ASTM, ASME, ANSI and other national and international standards.
API X Grades – some of the sturdiest pipes and tubing available designed for extreme environments or exceedingly high pressure environments
Type Carbon Steel LSAW Pipes
Pipe Size Sizes (Seamless): 1/2” NB - 60” NB Sizes (ERW): 1/2” NB - 24” NB Sizes (SAW): 16” NB - 100” NB
Wall Thickness SCH10,SCH20,SCH30,STD,SCH40,SCH60,XS,SCH80,SCH100,SCH120, SCH140,SCH160,XXS DIN, JIS standard thickness
Length Fixed: 5.8, 6.0, 11.8, 12.0m Random length: 5-12m
Standard ASTM A53, A106, API 5L, ASME B36.10M-1996 DIN1626, DIN1629, DIN17175, DIN 2448 JIS G3452, JIS G3454, JIS G3455, JIS G3456, JIS G3457, JIS G3461
Material Q235, Q345, A53B, A106B, API 5L B, X42, X46, X52, X60, X65 ST37.0, ST35.8, St37.2, St35.4/8, St42, St45, St52, St52.4 STP G38, STP G42, STPT42, STB42, STS42, STPT49, STS49
Application Low and middle pressure fluid pipeline, boiler, petroleum and natural gas industry, drilling, chemical industry, electric industry, shipbuilding, fertilizer equipment and pipeline, structure, petrochemical, pharmaceutical industry
Surface Black painting, varnish paint, anti rust oil, hot galvanized, cold galvanized, 3PE
Package Plastic caps on both ends, Steel bundle, Woven bag or acc. to customers' request
MOQ 1 ton
Production Capacity 5000 T/M
Delivery Time Within 2 Weeks
Best Rate Guarantee
 High Temperature Seamless Pipe ASTM A106 Gr. B/C, API 5L Gr. B, ASTM A53 Gr. B
 Heat Exchanger Seamless Tube ASTM A179
 Low Temperature Seamless Pipe ASTM A333 Gr. 3/6
 Low Temperature Seamless Tube ASTM A334 Gr. 6
 High Yield Seamless Pipe API 5L Gr. X42/X46/X52/X56/X60/X65/X70/X80 PSL-1/PSL-2
 High Yield Seamless Pipe ISO 3183 Gr.L245, L290, L320, L360, L390, L415, L450, L485
 Atmospheric & Low Temp EFW Pipes ASTM A671 Gr. CC60/CC65/CC70
 High Pressure & Moderate Temp EFW Pipes ASTM A672 Gr. B60/B65/B70/C55/C60/C65/C70
 High Yield ERW/SAW Pipe API 5L Gr. X42/X46/X52/X56/X60/X65/X70/X80 PSL-1/PSL-2
 High Yield ERW/SAW Pipe ISO 3183 Gr.L245, L290, L320, L360, L390, L415, L450, L485
Additional Testing: NACE MR0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc.
Dimensions: All Pipe is manufactured and inspected/tested to the relevant standards including ASTM, ASME, API.
LSAW STEEL PIPES Usage: Used for low pressure liquid delivery, such as water, gas, and oil. Process: LSAW (Longitudinal Submerge-arc Welded) UO(UOE), RB(RBE), JCO(JCOE) DSAW (Double Submerged arc welded)
Size: LSAW, DSAW: Outer Diameter: 219mm-1820mm Wall Thickness: 5.0mm-50mm Length: 6mtr-18mtr
Mill Test Certificate: EN 10204/3.1B Third party inspection: SGS, BV, Lloyds etc.
End:square ends (straight cut, saw cut, and torch cut). or beveled for welding, beveled
PSL 1

GRADE

Chemical Composition

Mechanical Property

C (Max)

Mn (Max)

P (Max)

S (Max)

TENSILE ( Min )

YIELD ( Min )

Psi X 1000

Mpa

Psi X 1000

Mpa

A25

CL   I

0.21

0.60

0.030

0.030

45

310

25

172

CL  II

0.21

0.60

0.030

0.030

A

0.22

0.90

0.030

0.030

48

331

30

207

B

0.26

1.20

0.030

0.030

60

414

35

241

X42

0.26

1.30

0.030

0.030

60

414

42

290

X46

0.26

1.40

0.030

0.030

63

434

46

317

X52

0.26

1.40

0.030

0.030

66

455

52

359

X56

0.26

1.40

0.030

0.030

71

490

56

386

X60

0.26

1.40

0.030

0.030

75

517

60

414

X65

0.26

1.45

0.030

0.030

77

531

65

448

X70

0.26

1.65

0.030

0.030

82

565

70

483

PSL 2

GRADE

Chemical Composition

Mechanical Property

C (Max)

Mn (Max)

P (Max)

S (Max)

Tensile

Yield

C. E.      IMPACT ENERGY

Psi x 1000

Mpa

Psi x 1000

Mpa

PCM

IIW

J

FT/LB

B

0.22

1.20

0.025

0.015

60 - 110

414 - 758

35 - 65

241 - 448

0.25

0.43

T/L 27/41

T/L 20/30

X42

0.22

1.30

0.025

0.015

60 - 110

414 - 758

42 - 72

290 - 496

0.25

0.43

T/L 27/41

T/L 20/30

X46

0.22

1.40

0.025

0.015

63 - 110

434 - 758

46 - 76

317 - 524

0.25

0.43

T/L 27/41

T/L 20/30

X52

0.22

1.40

0.025

0.015

66 - 110

455 - 758

52 - 77

359 - 531

0.25

0.43

T/L 27/41

T/L 20/30

X56

0.22

1.40

0.025

0.015

71 - 110

490 - 758

56 - 79

386 - 544

0.25

0.43

T/L 27/41

T/L 20/30

X60

0.22

1.40

0.025

0.015

75 - 110

517 - 758

60 - 82

414 - 565

0.25

0.43

T/L 27/41

T/L 20/30

X65

0.22

1.45

0.025

0.015

77 - 110

531 - 758

65 - 82

448 - 565

0.25

0.43

T/L 27/41

T/L 20/30

X70

0.22

1.65

0.025

0.015

82 - 110

565 - 758

70 - 82

483 - 565

0.25

0.43

T/L 27/41

T/L 20/30

X80

0.22

1.90

0.025

0.015

90 - 120

621 - 827

80 - 102

552 - 705

0.25

0.43

T/L 27/41

T/L 20/30

Whether you need Carbon Steel LSAW Pipes, standard length and diameter pipes and tubing or you need high strength, high tensile, heavy wall line pipe requirements for deep sour wells, drilling, offshore drilling, and production, arctic exploration and production, or you need Carbon Steel LSAW Pipes for natural gas, oil or water transport, then Canada Steel and Casing Imports can meet the demands of your company.
