API 5L X 60 PSL 1
Grade X60 indicates 60000 PSI minimum yield strength and 75000 PSI minimum ultimate tensile strength.
We can help supply all of the API 5L X 60 Pipe or line pipe supplies that your company needs for use in the oil or natural gas industries. API 5L Line Pipe Specifications for these pipes regulate usage for standard Grade A and Grade B pipes, with Grade X indicating stronger variants for drilling, production, and transport requirements for offshore, arctic, deep well, or harsher environments.
All products are industry-standard conforming to or exceeding API, ASTM, ASME, ANSI, and other national and international standards
API X Grades – some of the sturdiest pipes and tubing available designed for extreme environments or exceedingly high-pressure environments
API 5L X60 PSL1 Pipe Dimensional Range & Standard Specification
API 5L X60 PSL1 Pipe Dimensional Range:
Related Standard & Specification: API, DNV, ISO, DEP, EN, ASTM, DIN, BS, JIS, GB
Related Grade: API 5L A-X80, GB/T9711 L190-L555, ASTM A106/A53/A179/A192/A335/A333, DIN1629/17175, JIS G3454/ 3455/3456
Available Approved Marine: ABS/BV/LR/DNV/GL/KR, EN10204 3.2 MTC
Special Service: Sweet Service, Sour Service, Anti-H2S, NACE MR0175/ISO15156
Produce Process: Cold Drawn, Hot Rolled, Hot Expanded
Available Dimension Range: Available Length: 3-36Meters
|
API 5L X42 PSL1 Pipe Carbon Steel Pipes |
||||
|---|---|---|---|---|
|
Sr. No. |
Material |
Size |
Sch. & Swg. |
Specification |
|
1 |
Seamless Pipe |
15 NB To 150 NB |
Sch. 40s to Sch. XXs |
ASTM A 53 A / B A-106 Gr. A,B,C |
|
200 NB To 600 NB |
Sch. 20 to Sch. 160 |
|||
|
2 |
Welded (ERW) Pipe |
15 NB To 150 NB & 200 NB To 750 NB |
Sch. 40s to Sch. XXs & Sch. 20 to Sch. 160 |
ASTM A 53 A / B API 5L |
|
3 |
Low-Temperature Carbon Steel |
15 NB To 500 NB |
Sch. 40s to Sch. XXs |
A-333 Gr. 6 Seamless |
| Note:- | |
|---|---|
|
Trade name |
API 5L X60 PSL1 Pipe |
|
Other Specification Available |
API 5L – A,B, X – 42, 46, 52, 56, 60, 65, 70, 80 |
|
Special Tube |
Saw Pipes & Steam Pipes Precision Tubes Fabricated Pipe (with radiography) |
|
In Form of |
Round Hydraulic Tube & Horn Tube. |
|
In Length of |
Standard Double & In Cut length also. |
|
Value Added Service |
Draw & Expansion as per the required Size & Length Heat Treatment Bending Galvanizing Annealed Sand Blasting Machining Etc. |
|
Test Certificate |
Manufacturer Test Certificate IBR Test Certificate (Form III-D) Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection with Excise Gate Pass to avail Modvat benefit. |
| API 5L X60 | (PSL1) | (PSL2) |
|---|---|---|
| Minimum Yield Strength: | 60,200 psi | 60,200 psi |
| Maximum Yield Strength: | None | 81,900 psi |
| Minimum Tensile Strength: | 75,400 psi | 75,400 psi |
| Maximum Tensile Strength: | None | 110,200 psi |
| Notes: This is a standard line pipe grade specified in API (American Petroleum Institute) specification 5L. | ||
API 5L X60
API 5L X60 Seamless & Welded Pipe
API 5L X60 Butt Weld Fittings
API 5L X60 Forged Fittings
API 5L X60 Manifold Fittings
API 5L X60 Flanges
API 5L X60 Specialty Items
Production Standards & Material Qualities
| API 5L L245 / Gr. B (PSL 1) API 5L L290 / X42 (PSL 1) API 5L L245 / Gr. B (PSL 2) API 5L L290 / Gr. B (PSL 2) API 5L L320 / X46 (PSL 1) API 5L L320 / X46 (PSL 2) |
API 5L L360 / X52 (PSL 1) API 5L L360 / X52 (PSL 2) API 5L L415 / X60 (PSL 1) API 5L L415 / X60 (PSL 2) API 5L L450 / X65 (PSL 1) API 5L L450 / X65 (PSL 2) |
| Line Pipe API 5L, PSL 1, PSL 2 CSA Z 245.1 EN ISO 3183 GOST 20295 |
Gr A, X70-(N, M) Gr 241-Gr 359 L 245-L485 (N, M, NE, ME) K34-K60 |
Line pipe – types of steel
Tubes for transportation of flammable fluids are made of the following steels, according to EN 10208-1: L210GA, L235GA, L245GA, L290GA, L360GA, according to EN 10208-2: L245NB, L290NB, L360NB, L415NB and according to API 5L: Grade A, Grade B, Grade X42, Grade X46, Grade X52, Grade X60. Additional types of steel (according to DIN 2470-1/1629 and 2470-2/17172 and UNI 7088) together with its chemicals composition and mechanical properties are shown in a separate overview. Steel is made in the electric arc furnace and it is fully killed.
| CHEMICAL COMPOSITION | |||||||||||
| Mass fraction, based upon heat and product analysis % maximum | CARBON EQUIVALENT a | ||||||||||
| % MAXIMUM | |||||||||||
| Cb | Si | Mnb | P | S | V | Nb | Ti | Other | CEIIW | CEPcm | |
| SEAMLESS & WELDED PIPES | |||||||||||
| L485Q or X70Q | 0.18f | 0.45f | 1.8f | 0.025 | 0.015 | g | g | g | h | 0.43 | 0.25 |
| WELDED PIPE | |||||||||||
| L485M OR X70M | 0.12f | 0.45f | 1.7f | 0.025 | 0.015 | g | g | g | h | 0.43f | 0.25 |
| MECHANICAL REQUIREMENTS | |||
| Y.S | T.S | ELONGATION | |
| Mpa(psi) | Mpa(psi) | ||
| min | min | min | |
| 485(70 300) | 635(92 100) | f | |
| IMPACT TEST | |||
| AVG. ABSORBED ENERGY | IND. ABSORBED ENERGY | ||
| Min.(joules) | Min.(joules) | ||
| 27 | 20 | ||
Unless otherwise agreed, the sum of the niobium & vanadium concentrations shall be = 0.06%
Unless otherwise agreed, 0.50% maximum for copper, 0.30% maximum for nickel, 0.30% maximum for chromium, & 0.15% maximum for molybdenum.
The sum of the niobium & vanadium & titanium concentrations shall be =0.15%
Unless otherwise agreed, 0.50% maximum for copper, 0.30% maximum for nickel, 0.30% maximum for chromium, & 0.15% maximum for molybdenum.
Unless otherwise agreed g unless otherwise agreed the sum of the niobium & vanadium & titanium concentrations shall be =0.15%
Chemical Analysis(%) For Part Standard
Standard
| Class | Grade | C | Si | Mn | P | S | V | Nb | Ti | |
|---|---|---|---|---|---|---|---|---|---|---|
| max | max | max | max | max | max | max | max | |||
| APL 5L ISO 3181 |
PSL1 | L245 or B | 0.26 | - | 1.20 | 0.030 | 0.030 | - | - | - |
| L290 or X42 | 0.26 | - | 1.30 | 0.030 | 0.030 | - | - | - | ||
| L320 or X46 | 0.26 | - | 1.40 | 0.030 | 0.030 | a,b | a,b | b | ||
| L360 or X52 | 0.26 | - | 1.40 | 0.030 | 0.030 | b | b | b | ||
| L390 or X56 | 0.26 | - | 1.40 | 0.030 | 0.030 | b | b | b | ||
| L415 or X60 | 0.26 | - | 1.40 | 0.030 | 0.030 | c | c | c | ||
| L450 or X65 | 0.26 | - | 1.45 | 0.030 | 0.030 | c | c | c | ||
| L485 or X70 | 0.26 | - | 1.65 | 0.030 | 0.030 | c | c | c |
Mechanical Properties
Standard
| Class | Grade | Yield Strength MPa |
Yield Strength MPa |
Y.S/T.S | |||
|---|---|---|---|---|---|---|---|
| min | max | min | max | max | |||
| API 5L ISO3183 |
PSL2 | L245R or BR L245N or BN L245Q or BQ L245M or BM |
245 | 450 | 415 | 655 | 0.93 |
| L290R or X42R L290N or X42N L290Q or X42Q L290M or X42M |
290 | 495 | 415 | 655 | 0.93 | ||
| L320N or X46N L320Q or X46Q L320M or X46M |
320 | 525 | 435 | 655 | 0.93 | ||
| L360N or X52N L360Q or X52Q L360M or X52M |
360 | 530 | 460 | 760 | 0.93 | ||
| L390N or X56N L390Q or X56Q L390M or X56M |
390 | 545 | 490 | 760 | 0.93 | ||
| L415N or X60N L415Q or X60Q L415M or X60M |
415 | 565 | 520 | 760 | 0.93 | ||
| L450Q or X65Q L450M or X65M |
450 | 600 | 535 | 760 | 0.93 | ||
| L485Q or X70Q L485M or X70M |
485 | 635 | 570 | 760 | 0.93 | ||
| L555Q or X80Q L555M or X80M |
555 | 705 | 625 | 825 | 0.93 | ||
| L625M or X90M L625Q or X90Q |
625 | 775 | 695 | 915 | 0.95 | ||
| L690M or X100M L690Q or X100Q |
690 | 840 | 760 | 990 | 0.97 | ||
Minimum Impact Energy
Standard
| Specified Outside Diameter | Grade | Charp Imapct Test 0℃ | ||
|---|---|---|---|---|
| Impact of Pipe Body | Impact of Weld | |||
| API 5L ISO3183 |
D≤762mm | ≤L485 or X70 | 27 | 27 |
| L555 or X80 | 40 | 27 | ||
| 762mm< td="" style="box-sizing: border-box;"><> | ≤L555 or X80 | 40 | 27 | |
| 1219mm< td="" style="box-sizing: border-box;"><> | ≤L415 or X60 | 40 | 27 | |
| >L415 or X60 ≤L555 or X80 |
54 | 27 | ||
| >1422mm | ≤L415 or X60 | 40 | 40 | |
| >L415 or X60 ≤L555 or X80 |
54 | 40 | ||
API 5L X60 PSL1 Pipe – delivery condition and surface
Usually, API 5L X42 PSL1 pipes are supplied as hot rolled. Only tubes with DN 6 -10, perhaps tubes of other dimensions are supplied as cold drawn and after forming they are heat treated. This is done as per precious agreement. The tube surface meets corresponds to the means of manufacturing.
API 5L X60 PSL1 Pipe – straightness
Tubes are visually straight.
Ends of the API 5L X60 PSL1 Pipe
The ends of the tubes are smooth, without threads.
From 60.3 diameter beveled according to standards:
DIN, EN – a = 40° – 60°, c = to 2 mm
ASME – a = 75° ± 5°, c = 1,6 ± 0,8 mm
Marking of API 5L X60 PSL1 Pipe and tube bundles
Tubes with diameters up to 1 ½” are marked with a label on the bundle. Tubes with a larger diameter than 1 ½” are implemented according to directives or upon request.
API 5L X60 PSL1 Pipe – surface protection
Line pipes are supplied without temporary protection against corrosion. Upon request, it is possible to deliver tubes with agreed-upon anticorrosion protection. The tube ends may be enclosed by a plastic plug.
API 5L X60 PSL1 Pipe – testing
API 5L X60 PSL1 Pipe is tested according to the requirements of the appropriate standards. In all cases, the tube leaking test is performed. Tubes meet the directive requirements NACE MR 0175. covering resistance to acid environment (SSC – Sulfide Stress Cracking). When ordering the tubes it is possible to agree upon the carbon content value (CEV).
Whether you need API 5L X60 Pipe, standard length and diameter pipes and tubing or you need high strength, high tensile, heavy wall line pipe requirements for deep sour wells, drilling, offshore drilling and production, arctic exploration and production, or you need API 5L X60 Pipe for natural gas, oil or water transport, then Canada Steel and Casing Imports can meet the demands of your company.
